BIMEX MBBR 850 offers an optimal balance between performance and operational reliability, making it the ideal choice for municipal and industrial wastewater treatment applications requiring high efficiency and long-term stability.
APPLICATION
BIMEX MBBR 850 bio media is designed for use in biological wastewater treatment systems utilizing the Moving Bed Biofilm Reactor (MBBR) and Integrated Fixed-Film Activated Sludge (IFAS) technologies. Typical applications include:
- Municipal wastewater treatment plants (WWTP)
- Industrial wastewater treatment (food, beverage, petrochemical, fish, etc.)
- Biological oxidation (BOD/COD removal)
- Nitrification and ammonia removal
- Plant upgrades and capacity expansion
- Retrofit of conventional activated sludge system
DESIGN FEATURES
High Specific Surface Area
- Provides ≥ 850 m²/m³, enabling efficient biofilm growth and enhanced biological treatment performance.
Lightweight Design
- Manufactured from low-density HDPE, ensuring easy suspension, uniform distribution, and reduced energy consumption.
Anti-Clogging Design
- Open structure and controlled void ratio minimize clogging risk and maintain long-term performance
High Void Ratio (Porosity)
- Ensures excellent water flow, oxygen transfer, and effective contact between biomass and wastewater.
Optimized Geometry
- Wheel-type carrier with multiple internal chambers to maximize protected surface area and biofilm retention.
Enhanced Biofilm Protection
- Internal structure shields biomass from shear forces, improving process stability and performance.
Excellent Mixing Behavior
- Near-neutral density ensures uniform suspension and efficient contact with wastewater and oxygen.
High Mechanical Strength
- Robust construction suitable for continuous aeration and long operational life.
Long Service Life
- Manufactured from high-quality polymers resistant to chemicals, UV, and biological degradation.
Design & Operation Guidelines
- Recommended filling ratio: 40–70% of reactor volume
- Suitable for both aerobic and anoxic processes
- Requires proper screening and aeration system design
- Compatible with fine and coarse bubble aeration systems
